Wallas 30GB Diesel 3kW Variable Power Forced Air Heater
Broad Power Range and Versatility
- High air volume with optional boost feature.
- Multiple inlets allow for blended makeup air.
- Duplex exhaust allows for in cabin placement.
- Quiet, variable output eliminates system cycling.
- No exposed flame for safety, low case temperature.
- Thermostatic control panel for great comfort control.
- Low exhaust gas volume for safety & silent combustion.
- Wall mount included, feet for horizontal surface mounting.
- Superb corrosion free stainless and aluminum construction.
- Clean, reliable design, all brushless motors minimize servicing.
- Combustion gas & water vapor vented outside, keeps cabin dry.
The 30GB diesel heater is unmatched for simple control and reliability, using efficient proportional integral control. Heat sensing for thermostatic operation is taken at the control panel for maximum versatility and ease of installation.
The PI panel allows the user to choose simple variable speed ventilation, direct heat with variable output and/or thermostatic control of variable power. This robust control system has been in use for more than a decade with excellent results.
SPECIFICATIONS:
Heat output: 3,400 – 11,000 btu
Air vol. @ min. heat: 39cfm
Air vol. @ max. heat: 62cfm
Fuel type: Diesel #2, #1
Fuel consumption: 3.4 to 11.1 oz/hour
Weight: 20 lbs
Voltage: 12VDC
Starting amps: 9.0 for 5 min
Min. power amps: 1.0 (bare)*
Max. power amps: 2.0 (bare)*
*Adding ducting will reduce both air flow and resulting amperage draw
INCLUDED EQUIPMENT:
13 ft. fuel line, filter & adapters
13 ft. fused battery cables
PI Control panel w/19 ft cable
OPTIONS & ACCESSORIES:
#2467 – Exhaust through hull
#2460 – Closeable exhaust through deck
#1028 – 28mm SS flex exhaust pipe
#2045 – 45mm SS flex combustion air pipe
#2449 – Fiberglass insulation
#4030 – 33 liter fuel tank
#2027 – 10 liter fuel tank
#2024 – 5 liter fuel tank
#30011 – Fuel tank pickup
DIMENSIONS:
